Ⅰ. Product Description
The Anti-Drone Radar System represents a quantum leap in persistent aerial threat detection, delivering uninterrupted 24/7 surveillance through its multi-layered sensor fusion and intelligent system integration. Designed for mission-critical security operations, this advanced system combines phased array radar, AI-powered spectrum analysis, and adaptive countermeasures to protect high-value assets including installations, airports, and government facilities.
At the heart of the system lies its dual-mode detection architecture integrating active radar (5400-5600MHz ISM band) with passive RF detection (20MHz-6GHz) to achieve comprehensive airspace awareness. The system's open API framework enables seamless integ ration with existing security infrastructure, including CCTV networks, command centers, and air defense systems, creating a unified security ecosystem.
Engineered for continuous operation, system features self-healing capabilities and remote diagnostics, maintaining 99% system availability even in extreme environments (-40°C to 55°C). Its modular design supports configurations ranging from standalone protection to distributed defense networks, ensuring scalable security for any operational scenario.
Ⅱ. Product Features
1. Intelligent Multi-Sensor Detection
Phased Array Radar
5400-5600MHz operating frequency (ITU-compliant ISM band)
≥7.5km detection range for standard drones
multiple target simultaneous target tracking capability
Full-Spectrum RF Analysis
20MHz-6GHz frequency coverage
Protocol-specific identification (DJI, Autel, custom protocols)
5km passive detection range
2. Adaptive Counter-Drone Suite
Precision Electronic Warfare
Targeted jamming (840-868MHz, 2.4GHz, 5.8GHz)
GPS/GNSS spoofing (L1/L2/L5 bands)
Automated Response Protocols
Pre-programmed defense sequences
Manual override capability
3. Multi-Domain Deployment Flexibility
Fixed-Site Configuration
Permanent installations for critical infrastructure
Mobile Platforms
Vehicle-mounted for rapid deployment
Maritime Solutions
Saltwater-resistant variants for coastal defense
Ⅲ. Product Functions
| Functional Indicators | Main Performance |
| System Detection Configuration | Radar Operating Band | 5400-5600MHz (ISM band exempt from application by International Telecommunication Union) |
| Spectrum Detection Band | 20MHz-6GHz full band |
| Operational Range | Identification Range: ≥5km (capable of identifying drone brands and models) |
| Detection Range: ≥7.5km (detects drones in the database and those using non-database communication protocols) |
| Unauthorized Flight Detection Range: ≥2km (detects all drones, including FPV and unauthorized flights) |
| Detection Success Rate | 99% |
| Protocol Cracking | LightBridge1, LightBridge2; OcuSync; WIFI and WIFI variant protocols |
| Deception Takeover | Deception Frequency | GPS-L1 |
| Deception Range | 3km (adjustable) |
| Jamming Suppression | Jamming Bands | 840-868MHz(flight control and video transmission) |
| 902-928MHz(flight control and video transmission) |
| 1560-1620MHz (navigation) |
| 2400-2500MHz(flight control and video transmission) |
| 5150-5850MHz(flight control and video transmission) |
| Operational Range | 1000m |
Ⅳ. Product Parameters
| Parameter Indicators |
| Dimensions (when deployed) | ≤1500mm×1500mm×2800mm |
| Weight | ≤25kg (equipment) |
| Operating Temperature | -40℃～55℃ |
| Storage Temperature | -45℃～65℃ |
| Protection Rating | Ip65 |
| Operating Humidity | ≤ 95% |
| Data Interface | RJ45 |
| Power Interface | Voltage: AC 180V-250V |
| Power: ≤100W (detection mode), ≤600W (countermeasure mode) |
| Setup Time | ≤15min |
| Packaging | 2 cases |
| Platform Functions | Real-time detection, alarm, automatic countermeasures, manual countermeasures, GIS mapping, data storage, event query |
